APC MATRIX 5000 MX5000 208V 5 KVA Ups

4 ad 12v 18a akü mevcuttur. 1 akü kabı içerisinde 4 ad akü takılıdır.

The APC Matrix 5000 has been professionally tested and refurbished. This APC Matrix 5000 comes with 2 SmartCells with brand new batteries installed. The unit is in excellent condition with minor scratches from storage and movement. The unit is 100% functional and comes with a 1 year warranty.


The APC Matrix 5000 has an input of 208V NEMA L6-30P and needs a dedicated 208V 30A power line. Please speak with your site manager or electrician to ensure that you have this power available to you.


The APC Matrix 5000 has a digital display with many options to allow for easy and convenient configuration. The APC Matrix can also be configured using APC's PowerChute Business Edition, available free of charge online at APC.com.


The APC Matrix 5000 is an excellent industrial unit, a work horse providing 3750W / 5000VA of power. The Matrix 5000 comes standard with two SmartCell Battery Packs. If more runtime is needed, up to 10 SmartCells can be attached in a cascading order to the Matrix. If even more runtime is required a SmartCell XR battery pack can be purchased which contains huge batteries and offers a significantly longer runtime.

Typical runtime with two APC SmartCells:





Typical backup time
at half load

27.8 minutes (1875 Watts)

Typical backup time
at full load

10.2 minutes (3750 Watts)



Adjustable voltage-transfer points
Audible alarms
Automatic internal bypass
Automatic restart of loads after UPS shutdown
Automatic self-test
Battery modules connected in parallel
Boost and Trim Automatic Voltage Regulation (AVR)
Field-replaceable power distribution panel
Hot-swappable batteries
Hot-swappable modules
InfraStruXure Manager compatible
Intelligent battery management
LCD display
Manageable external batteries
Modular design
Plug-and-Play external batteries
Power conditioning
Predictive failure notification
Scalable runtime
Serial Connectivity
SmartSlot
User-replaceable batteries
User-replaceable power modules


Output:

Output power capacity

3750 Watts / 5000 VA

Max Configurable Power

3750 Watts / 5000 VA

Nominal output voltage

120V,208V

Efficiency at Full Load

93.00%
Output Voltage Distortion

less than 5% at full load

Output Frequency (sync to mains)

57 - 63 Hz for 60 Hz nominal

Crest Factor

up to 5 : 1

Waveform type

Sinewave

Output Connections
(6) NEMA 5-15R



(1) NEMA L14-30R
(2) NEMA L6-30R
Input:

Bypass

Internal Bypass (Automatic and Manual)

Nominal input voltage

208V

Input frequency

60 Hz +/- 5 Hz
Input Connection Type
NEMA L6-30P



Cord Length

6 feet ( 1.83 meters )

Input voltage range for main operations

156 - 252 (208) / 176 - 282 ( 240V)V

Batteries and Runtime:

Battery type

Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof

Replacement battery cartridge

The MX5000 ships with 2-SmartCell's. There is no RBC available for a standard SmartCell.

RBC™ Quantity

2

Typical backup time
at half load

27.8 minutes (1875 Watts)

Typical backup time
at full load

10.2 minutes (3750 Watts)

Runtime Chart

Matrix-UPS

Communications and Management:

Interface port

DB-9 RS-232,SmartSlot

Available Smart Slot Interface Quantity

1

Control panel

Multi-function LCD status and control console

Audible alarm

Alarm when on battery : distinctive low battery alarm : configurable delays

Emergency Power Off (EPO)

Yes

Physical:





Maximum height

683.00 mm

Maximum width

351.00 mm

Maximum depth

452.00 mm

Net weight

137.73 KG

Shipping Weight

160.00 KG
