Specifications
General
CPU Onboard low power STPC Elite 133 MHz
2nd Cache Memory On processor
System Chipset STPC® Elite embedded
BIOS AWARD® 256 kbit Flash BIOS
System Memory On board 32 MB SDRAM
(optional 1 x SDRAM SODIMM, Max. 64 MB)
Power Management APM
SSD DiskOnChip® 2000 (optional CompactFlash® card)
Watch Dog Timer 1 ~ 62 sec., System reset or IRQ11
Expansion Interface 1 x 16-bit ISA slot, 1 x PC/104 connector
Battery Lithium 3 V/196 mAH
I/O
I/O Interface 1 x EIDE (PIO Mode 4), 1 x FDD, 1 x K/B,
1 x Mouse, 1 x LPT
PCA-6740F-0CA2: 1 x RS-232/422/485, 1 x RS-232;
PCA-6740L-0CA2: 2 x RS-232;
USB N/A
Audio N/A
IrDA 115 kbps SIR, IrDA 1.0 compliant
GPIO N/A
I/O Expansion PC/104, ISA
Ethernet
Chipset RTL™ 8139C
Speed 10/100Base-T
Interface 1 x RJ-45
Standard IEEE 802.3u
Built-in boot ROM
Display
Chipset SMI Lynx 712
Memory Size 4 MB
Resolution CRT mode: 1280 x 1024 @ 16 bpp (60 Hz),
1024 x 768 @ 16 bpp, 800 x 600 @ 16 bpp
LCD mode: 1280 x 1024 @ 16 bpp (60 Hz)
1024 x 768 @ 16 bpp, 800 x 600 @ 16 bpp
LCD Interface Up to 36-bit TTL for TFT LCD
LVDS Interface N/A
TV-Out N/A
Dual Independent N/A
Display
Mechanical and Environmental
Dimension (L x W) 185 x 122 mm (7.3” x 4.8”)
Weight 0.27 kg (weight of total package)
Operating Temperature 0 ~ 60° C (32 ~ 140° F), operation
Operating Humidity 0% ~ 90% relative humidity, non-condensing
Power
Power Supply Voltage +5 V ± 5%
Power Consumption Max : 5 V @ 2 A
Typical : 5 V @ 1.62 A
